Pinging between two workstations on different subnet

Console Based   |    GUI Based

Console Based:

Description: Lab Exercise explains pinging between two work station on different subnets

Note: A layer 2 switch works transparently in a network. There is no need to configure a Layer 2 Switch for performing basic operations of forwarding frames. However, for using advanced functionality like port security, VLAN configuration, etc. one may need to configure a Switch.

Instructions:

1. Click network diagram button and select device WS1 from network diagram.

2. Configure 192.168.10.1/24 as ip address and default-gateway as 192.168.1.1

3. Select device WS2 from network diagram and configure ip address 192.168.20.1/24 and default-gateway 192.168.1.1.

4. Ping WS1 from WS2 and you get ping failed message because both work stations are on
different subnets.

GUI Based :

Instructions:

1. To assign ip address to WS1 select WS1 from Select device drop down , and click PC IPV4 properties from left navigation pane

2. PC IPV4 properties window appears , click option button Use the following ip address , ip address will get enabled and enter ip address as 192.168.10.1 , mask as 255.255.255.0 and default-gateway 192.168.1.1 and click OK button.

3. To assign ip address to device WS2 , select the device WS2 from left navigation pane and click PC IPV4 properties from left navigation pane

4. PC IPV4 properties window appears , click option button Use the following ip address , ip address will get enabled and enter ip address as 192.168.20.1 , mask as 255.255.255.0 and default-gateway 192.168.1.1 and click OK button.

5. To ping from WS1 to WS2 or WS2 to WS1 click trouble shoot button to enable the Troubleshoot left pane select Ping Host from left pane Ping/traceroute window appears enter the ip address 192.168.1.2 in the Ping field and click OK button.

6. Repeat step 5 for device WS2. You get ping failed message because both work stations are on
different subnets.

Note: Please refer to the CertExams.com Juniper Network Simulator software for complete lab with GUI Interface.
